HD BEAM BUILDING

The HD Beam Building expertly combines the I-Beam frame and ClearSpan’s exclusive Armor Shield Cover, resulting in a building that can be built on a large scale, without sacrificing any structural integrity or durability.

ClearSpan’s HD Beam Building is the ideal structure for those who value size, but won’t compromise structural integrity or safety. The HD Beam can be scaled to any size to match the needs of any business in any industry. These buildings come stock or can be highly customized to fit different types of operations. From storage to manufacturing, this structure can be utilized in thousands of different ways.

The HD Beam is constructed using an I-Beam frame, one of the sturdiest frames ClearSpan has offered in its 40-year history. The frame, purlins and cladding are all crafted from galvanized steel to ensure a long-lasting life and superior stability. It also features a 4:12 pitched roof with a 12’ nominal eave height and 10’ clearance at the eave, ensuring seamless movement in and around the building. This structure can be outfitted with solid end walls or end walls that feature a man door and a main doorframe that measures 12’ by 12’ or 14’ by 14’, depending on the width of the building.

Covering the structure is ClearSpan’s exclusive Armor Shield cover, crafted from 29 oz architectural vinyl. The Armor Shield Cover consists of seven layers, including a sturdy base fabric, multiple layers of protective coating and dual-sided PVDF topcoat that increases durability and repels dirt. This creates a long-lasting tensile fabric of the highest quality.

The ClearSpan HD Beam Advantage Includes:

  • A Building of 1,000 uses – Perfect for any industry
  • I-Beam construction – Strength and dependability
  • 29 oz. Architectural vinyl cover – Constructed from 7 layers of strong material
  • Scale to any size – Perfect for large operations
  • 4:12 roof pitch
  • 12’ nominal eave height, 10’ clearance at the eave
  • End wall options available
  • Frame and purlins made from grade 55 galvanized steel
  • Industry-leading warranties – 50 years on the frame, 30 on the Armor Shield cover

Dependable for years to come

ClearSpan’s triple-galvanized, American-made steel offers a sturdy, anti-corrosive frame that comes covered with a gray primer. This structure stands up to the toughest weather patterns and can withstand the harshest climates. ClearSpan stands behind the HD Beam’s longevity by offering a 50-year warranty on the I-Beam frame and 30 years on the Armor Shield Cover.

To find out more about ClearSpan’s HD I-Beam Building and pricing call or Request a Quote today.
